| The weight of the 12-meter beam | |
| Beam size (cm) | The weight of the 12 meters beam (kg) |
| 8 | 72 |
| 10 | 98 |
| 10 | 53 |
| 12 | 125 |
| 14 | 155 |
| 16 | 190 |
| 18 | 226 |
| 20 | 269 |
| 22 | 315 |
| 27 | 434 |
| 30 | 507 |
| 33 | 590 |
| 36 | 686 |
| 40 | 796 |
| 45 | 932 |
| 50 | 1089 |
| 55 | 1272 |
| 60 | 1464 |
| Comparison of factory beam weight table | |||||||||
| Weight of each beam branch (size) | 14 | 16 | 18 | 20 | 22 | 24 | 27 | ||
| Fico's beam weight (kg) | 125 | 165 | __ | 140-250 | __ | __ | __ | ||
| Arian Steel's beam weight (kg) | 135 | 185 | 215 | 205 | 315 | 360 | 435 | ||
| West steel's beam weight (kg) | 126 | 189/6 | 225/6 | 268/8 | __ | __ | __ | ||
| Shahin Bonab's beam weight (kg) | 124-130 | __ | __ | __ | __ | __ | __ | ||
| Zafar Bonab's beam weight (kg) | 135-125 | __ | __ | __ | __ | __ | __ | ||
| Tabriz steel's beam weight (kg) | 130 | __ | 205-210 | __ | __ | __ | __ | ||
| West Kermanshah steel's beam weight (kg) | 132-140-150 | Fabric | __ | __ | __ | __ | __ | ||
| Iran steel's beam weight (kg) | 132 | 165 | __ | __ | __ | __ | __ | ||
| Alborz steel beam weight (kg) | 171/6 | 214/8 | 262/8 | __ | __ | __ | __ | ||
| Mahan profile beam weight (kg) | 130-128-132-119 | 165 | 195-200 | __ | __ | __ | __ | ||
| Mahan profile beam weight (kg) | Super light 93-97 | __ | __ | __ | __ | __ | __ | ||
